AEROSPACE CRANE SOLUTIONS

Aerospace Composite Production Crane Fleet

An expanding aerospace composites workshop needs enough crane coverage for repeated production lifts without blocking adjacent stations.

ApplicationXi'an aerospace composites production facility
Project equipmentBuilt for this handling task
Site-specificLoad, route, duty and delivery scope
Overhead crane serving an aerospace composite production workshop
Overhead crane serving an aerospace composite production workshop.
THE OPERATING CHALLENGE

Start with the component and the lift route.

An expanding aerospace composites workshop needs enough crane coverage for repeated production lifts without blocking adjacent stations.

The lifted component, rigging, building clearances and control sequence need to be reviewed as one operating system.

Prepare the technical brief ↗
01 / DEFINE

Part and fixture schedule

02 / DEFINE

Bay spans and crane overlap

03 / DEFINE

Production ramp-up and shifts

04 / DEFINE

Acceptance and maintenance plan

ENGINEERED FOR THE APPLICATION

Scale lifting coverage as aerospace composite output grows.

Plan the fleet by production cell, component envelope and fixture schedule. Different spans and capacities can share control and maintenance standards while each crane retains a task-specific lifting arrangement.

Overhead crane serving an aerospace composite production workshop
Overhead crane serving an aerospace composite production workshop.
01

Map production cells

Identify part movement from fabrication through assembly and dispatch.

02

Allocate crane duty

Set reach and capacity for each bay rather than one oversized unit.

03

Phase installation

Commission cranes alongside the planned output ramp-up.

✓

High-value parts

Define protected attachments and slower movement near tooling.

✓

Fleet consistency

Standardize service, training and inspection across multiple installed cranes.

PROJECT IN OPERATION

Xi'an aerospace composites production facility

More than 20 long-span, high-precision cranes were ordered for an aerospace composites institute, with 12 units delivered at the time of the project update.

Process fitAerospace Composite Production Crane Fleet Solution
EquipmentKSQ New-Design Hook Overhead Crane / QJ Lower-Rotating Carrier-Beam Crane
ProjectXi'an aerospace composites production facility
Technical reviewCustomer load and site drawings
SPECIFICATION FOR YOUR SITE

Define the operating brief before fixing a crane model.

Project figures above describe a delivered application. Your crane rating, dimensions, controls and documentation follow the approved site brief.

InputInformation needed for this applicationConfirm in the technical offer
01 / Site requirementPart and fixture scheduleRated load including the attachment, lifting-point arrangement and load cases.
02 / Site requirementBay spans and crane overlapCrane span, lifting height, headroom, wheel loads and runway or foundation interfaces.
03 / Site requirementProduction ramp-up and shiftsDuty classification, speeds and control behaviour matched to the agreed operating cycle.
04 / Site requirementAcceptance and maintenance planProtection, positioning, interlocks, monitoring and safe recovery requirements.
Destination and deliveryCountry, project standards, quantity, freight and site services.Documents, inspection and testing, packing, installation support and agreed delivery milestones.
Have a preliminary layout?

Send the available load schedule and drawings. The missing inputs can be identified during technical review.

Discuss your project ↗
FROM OFFER TO HANDOVER

Compare the complete lifting package.

The offer should state the equipment boundary, documents, inspections and site responsibilities for your destination.

01

Engineering

General arrangement, load basis, runway and utility interfaces, control and protection schedule.

02

Manufacture & inspection

Approved drawings, inspection plan and factory testing for the selected configuration.

03

Shipping & site work

Packing, freight, erection support, commissioning and operator training as specified.

04

Handover

Test records, manuals, maintenance instructions and agreed spare-parts list.

Order quantity, compliance and delivery schedule

Single-crane and multi-crane packages are available. Your quotation defines the destination standards, required certificates and inspection records, packing, site services and production schedule after drawing approval.

BUYER QUESTIONS

Before you request a quotation.

What information is needed to specify this crane solution?

Send the full load and lifting-gear mass, route or bay drawing, operating cycles, working environment, controls and destination requirements.

Can the lifting system be configured for our component and workshop?

Yes. The equipment arrangement, attachment and controls are selected for the approved load, route, runway and process conditions.

What are the order quantity, certification and lead time?

We can quote a single crane or a coordinated fleet. The project offer states the agreed destination standards, inspection and test documents, manufacturing schedule after drawing approval, and shipping or site-service scope.

LET'S REVIEW YOUR PROJECT

Send your project brief. Get a crane proposal built around your process.

Share your load, layout, work cycle and destination. Our team can review the crane, lifting attachment and delivery scope together.
