Composite dimensions and mass
Aerospace Composite Rotation Crane
Composite aerospace parts can be long, sensitive to local contact and difficult to orient with a fixed hook.

Start with the component and the lift route.
Composite aerospace parts can be long, sensitive to local contact and difficult to orient with a fixed hook.
The lifted component, rigging, building clearances and control sequence need to be reviewed as one operating system.
Prepare the technical brief ↗Fixture and lift-point drawings
Rotation envelope
Loaded positioning test method
Rotate composite structures accurately during manufacturing.
Use a lower-rotating crane with a dual-attachment arrangement matched to the actual fixture. Model the structure and verify rotation, load sharing and sub-millimeter control requirements against the test plan.

Support the part
Set attachment positions where the composite structure can be lifted safely.
Rotate in the bay
Check sweep clearance and synchronized motion through the required angle.
Place at the fixture
Approach slowly and confirm alignment before release.
Fixture interface
Validate the part-support method and surface protection with the manufacturer.
Test precision
Specify how positioning accuracy will be measured under load.
Xi'an aerospace composites institute
A lower-rotating crane for the Xi'an aerospace composites institute passed its load test. The unit used a dual-attachment design and a stated control-precision target below 1 mm.


Define the operating brief before fixing a crane model.
Project figures above describe a delivered application. Your crane rating, dimensions, controls and documentation follow the approved site brief.
| Input | Information needed for this application | Confirm in the technical offer |
|---|---|---|
| 01 / Site requirement | Composite dimensions and mass | Rated load including the attachment, lifting-point arrangement and load cases. |
| 02 / Site requirement | Fixture and lift-point drawings | Attachment geometry, lifting-point loads, load sharing and the approved interface with the part. |
| 03 / Site requirement | Rotation envelope | Required rotation angle, swept clearance, synchronized motions and limits through the full handling route. |
| 04 / Site requirement | Loaded positioning test method | Positioning tolerance under the agreed test load, measurement method, test positions and acceptance criteria. |
| Destination and delivery | Country, project standards, quantity, freight and site services. | Documents, inspection and testing, packing, installation support and agreed delivery milestones. |
Send the available load schedule and drawings. The missing inputs can be identified during technical review.
Discuss your project ↗Compare the complete lifting package.
The offer should state the equipment boundary, documents, inspections and site responsibilities for your destination.
Engineering
General arrangement, load basis, runway and utility interfaces, control and protection schedule.
Manufacture & inspection
Approved drawings, inspection plan and factory testing for the selected configuration.
Shipping & site work
Packing, freight, erection support, commissioning and operator training as specified.
Handover
Test records, manuals, maintenance instructions and agreed spare-parts list.
Single-crane and multi-crane packages are available. Your quotation defines the destination standards, required certificates and inspection records, packing, site services and production schedule after drawing approval.
Compare equipment for this operating task.
These product families and related applications provide a starting point. Final selection follows the load and site review.
Before you request a quotation.
What information is needed to specify this crane solution?
Send the full load and lifting-gear mass, route or bay drawing, operating cycles, working environment, controls and destination requirements.
Can the lifting system be configured for our component and workshop?
Yes. The equipment arrangement, attachment and controls are selected for the approved load, route, runway and process conditions.
What are the order quantity, certification and lead time?
We can quote a single crane or a coordinated fleet. The project offer states the agreed destination standards, inspection and test documents, manufacturing schedule after drawing approval, and shipping or site-service scope.
Send your project brief. Get a crane proposal built around your process.
Share your load, layout, work cycle and destination. Our team can review the crane, lifting attachment and delivery scope together.
Send your project requirements ↗
