LXB / COMBUSTIBLE-DUST LIFTING

LXB Dust Explosion-Proof Suspension Crane

Handle equipment and maintenance loads in grain, feed and other combustible-dust processing areas. This LXB configuration combines an underhung single girder with a dust-protected hoist, travel drives and controls selected for the site's dust classification and permitted surface temperature. Plan the lifting coverage around your process equipment and routine service tasks.

HELP CHOOSING YOUR CRANE

Start with the load, approximate working span and type of dust at your site. Include an existing area-classification document if available; we can help you choose the crane arrangement.

Rated capacity
1–10 t
Span
7.5–28.5 m
Lifting height
6–20 m
Protection
Combustible-dust atmosphere
Dust-area protectionSuspended single girder

Start with the dimensions you already know. A workshop photo or sketch can help us recommend a configuration.

01
Reach service points across the process bay

The suspended bridge and cross-travelling hoist can be arranged around the equipment positions you need to reach. Specify the removal, transfer and replacement route for the load.

02
Select protection around the actual dust

Match the hoist, drives, controls and enclosures to the dust group, zone and surface-temperature requirement. The proposed equipment and applicable documents are identified in the technical offer.

03
Plan access and operating support

Include the access needed for inspection, cleaning and maintenance in the layout discussion. Agree the supplied manuals, installation assistance, spare parts and service scope with the crane package.

LXB Dust single-girder crane overall view showing the bridge, end carriages and hoist
LXB dust-protected equipment layout — complete crane arrangement
01 / APPLICATIONS

Handling in dust-classified process areas.

01

Grain and feed equipment service

Remove and reinstall motors, drives and process components above grain or feed machinery. Select the lifting range for access to the equipment and the protection package for the classified dust area.

02

Powder-processing machinery

Position machinery parts and maintenance loads around a powder-handling line. Define the lifting points, heaviest load and dust classification to choose the suspended crane and protected equipment.

03

Dust-collection equipment maintenance

Support component removal and replacement around dust-collection equipment. Match hook access and lifting height to the work, with the dust-protection rating and equipment surface temperature selected for the location.

Dust protection is selected from the area classification and material characteristics. Gas-protected configurations are specified separately.

02 / TECHNICAL SPECIFICATIONS

LXB specifications and configuration options

Compare the available options for your lifting task. Capacity, span, lift height and speed are matched in the selected configuration.

Rated capacity1–10 t; custom loads available
Span7.5–28.5 m; custom layouts available
Lifting height6–20 m
Working classA3–A5
Hoisting speed2–10 m/min
Crane travel speed15–25 m/min
Hoist trolley travelConfigured to span, positioning and handling cycle
Hoist typeDust explosion-protected electric hoist
Drive motorsDust explosion-protected travel motors
ControlDust explosion-protected pendant / suitable remote control
Power supply380 V, 50 Hz, 3-phase; export supply options
Explosion-protection markingSelected to dust group, zone and surface-temperature limit
Enclosure protectionIP65
Operating temperature−20°C to +45°C; matched to environment
Bridge structureUnderhung single girder
Typical applicationGrain, feed and combustible-dust processing areas
Classification inputsDust group, zone and ignition temperature
03 / EQUIPMENT VIEWS

LXB dust-protected equipment views.

See the bridge, end carriages and hoist from three angles. The quoted crane includes the dust-protection package selected for your working area.

LXB Dust single-girder crane perspective view showing the bridge, end carriages and hoist
LXB dust-protected equipment layout — bridge and hoist perspective
LXB Dust single-girder crane reverse view showing the bridge, end carriages and hoist
LXB dust-protected equipment layout — alternative equipment view
04 / CONFIGURATION

A dust-specific package for your lifting task.

Choose the lifting arrangement and handling speeds together with the dust-protected equipment, enclosures, controls and site power supply.

LXB Dust single-girder crane reverse view showing the bridge, end carriages and hoist
LXB dust-protected equipment layout — alternative equipment view
01 / OPTION

Load and working range

Select the capacity for the load and its lifting attachments, then match span and hook travel to the equipment positions. Compare the 1–10 t series or request a custom arrangement for your handling task.

02 / OPTION

Dust protection

Specify the dust material, group, zone and required surface-temperature limit. An existing area-classification document and relevant ignition-temperature data help define the protected hoist, drives and controls.

03 / OPTION

Protected equipment and enclosures

Match the protected motors, control equipment and enclosures to the dust classification. IP65 enclosure protection is listed for this series; the dust-protection marking and applicable documents are specified for the selected equipment.

04 / OPTION

Speeds, controls and power

Select lifting and travel speeds for routine handling or equipment positioning. Compare a suitable pendant or remote control, and specify your site voltage and frequency for the electrical package.

05 / PURCHASING & DELIVERY

What comes with your LXB crane?

Compare the suspended bridge, dust-protected hoist, travel drives, controls and power feed in your offer. Agree the equipment documents, runway/support scope, delivery, site assistance, warranty and recommended spares for the selected configuration.

ORDER QUANTITY

One crane or a workshop package

Single-crane enquiries are welcome. Request one unit or a coordinated package for several working bays.

QUOTATION

See the equipment included

Your quotation lists the bridge, protected hoist, travel drives, controls and power feed. Runway beams, support steelwork, lifting attachments, packing, freight and installation services are identified separately where required.

DOCUMENTS

Documents for your destination

The offer lists drawings, electrical documents, operating manuals and inspection records, plus the protection documents applicable to the selected dust-rated equipment. Include your destination and required approvals in the enquiry.

DELIVERY

Delivery time in your quotation

Manufacturing lead time and dispatch dates are confirmed for your selected crane. Shipping time depends on the destination and transport plan.

INSTALLATION

Installation support

Ask for installation guidance, commissioning assistance or site support with the equipment offer. The agreed scope identifies the crane and runway interfaces and the service arrangements for your location.

WARRANTY & SPARES

Warranty and spare parts

The offer confirms the warranty period and coverage, service contact and spare-parts support. Ask for recommended spares for the selected dust-protected hoist, travel drives and controls.

07 / BUYER QUESTIONS

Answers for your LXB crane purchase

Find the arrangement, equipment options and order information that suit your application.

What is the LXB dust-protected configuration used for?

This configuration is selected for lifting equipment and maintenance loads in a classified combustible-dust area. Typical applications include grain, feed and dust-processing workshops where an underhung crane suits the building layout and required working coverage.

How does dust protection differ from gas protection?

Dust selection uses the dust group, zone and permitted equipment surface temperature, with the dust's ignition characteristics taken into account. Gas selection uses the gas group, zone and temperature class. Identify both hazards when they are present in the same working area.

Which information should I send about the dust?

Provide the material handled and any available group, zone and ignition-temperature information. An existing area-classification document is useful. You can begin the crane layout discussion with the load, working dimensions and process description while the classification information is assembled.

What load and span options can be reviewed?

The published selection range is 1–10 t capacity, 7.5–28.5 m span and 6–20 m lifting height, with custom configuration enquiries available. Capacity, layout, operating duty and protection package are matched for the proposed crane.

What does the listed IP65 enclosure protection cover?

IP65 describes enclosure protection against dust ingress and water jets. For a classified combustible-dust installation, the offer must also identify the selected dust-protected equipment, its marking and the applicable documents for the stated area.

Can we retain our existing suspended runway?

Share its dimensions, support positions, drawings and available condition information. The technical proposal can review the crane/runway interface and identify support verification, runway work and supply boundaries for the selected crane.

Can lifting speeds and operator controls be selected for the process?

Yes. Describe the load movements, placement task and operator position so lifting/travel selections and a suitable pendant or remote control can be specified. The controls and drives are selected with the required dust-protection package and site power supply.

Which protection and operating documents should be included?

Request the selected equipment's dust-protection markings and applicable certificates, together with arrangement and electrical drawings, manuals and inspection records. State any destination approval requirement in the enquiry so the quotation can identify the available documentation.

Can one crane be supplied with installation support and spares?

Single-crane enquiries are welcome. Ask the offer to identify the bridge and protected lifting package, runway/support work, packing, freight, installation or commissioning support, warranty coverage and recommended spares for the agreed equipment.

08 / YOUR LXB CRANE PROJECT

Request your LXB dust-protected crane quotation.

Tell us the load, approximate span, lifting height and project country, plus the material handled in the area. Add the available dust classification or a workshop sketch. We can help define a practical crane arrangement and a clear equipment offer.
