Two Automated Cranes for Power Cable and Utility Equipment Handling
Two cranes combine encoder feedback, 3D scanning and WCS/WMS integration for automated handling in a utility warehouse and production setting.
The project and its handling task.
Henan Mine Crane customized two automated cranes for a power-industry project. Their duty includes handling power cables associated with packaged substations and related utility materials.
The systems use inverter and PLC control, hoist encoders and Gray-code bus positioning on travel axes. 3D scanning and vision inspection support recognition, pickup, positioning and obstacle avoidance, with anti-sway and detection switches on the intelligent attachment.
Identify, lift and trace electrical materials without manual travel.
Power projects store cable and other electrical items with changing locations, so an automated crane must know both the load and its destination.
Use scanning and visual checks to match a load with its warehouse record.
Engage the monitored attachment and follow the assigned route with obstacle checks.
Confirm placement and write the movement to the inventory system.
Confirm placement and write the movement to the inventory system.
The equipment behind this project.
The systems use inverter and PLC control, hoist encoders and Gray-code bus positioning on travel axes. 3D scanning and vision inspection support recognition, pickup, positioning and obstacle avoidance, with anti-sway and detection switches on the intelligent attachment.
- Quantity2 automated cranes
- Hoist feedbackEncoders
- Travel positioningGray-code bus positioning
- Recognition3D scanning and vision inspection
- Warehouse integrationWCS scheduling and WMS inventory management
- Data captureHandling-process records on a dedicated control-room server
What to compare with your own project.
Match the project configuration to your load, layout and operating sequence before selecting a crane package.
| Design area | This project configuration | Define for your site |
|---|---|---|
| Quantity | 2 automated cranes | Cable package dimensions and mass. Define the required operating envelope and acceptance checks in your technical brief. |
| Hoist feedback | Encoders | Storage and vehicle layout. Define the required operating envelope and acceptance checks in your technical brief. |
| Travel positioning | Gray-code bus positioning | Inventory and WCS/WMS interfaces. Define the required operating envelope and acceptance checks in your technical brief. |
| Recognition | 3D scanning and vision inspection | Obstacle, sway and release rules. Define the required operating envelope and acceptance checks in your technical brief. |
| Warehouse integration | WCS scheduling and WMS inventory management | Cable package dimensions and mass. Define the required operating envelope and acceptance checks in your technical brief. |
| Data capture | Handling-process records on a dedicated control-room server | Storage and vehicle layout. Define the required operating envelope and acceptance checks in your technical brief. |
See the equipment and working environment.
Explore the equipment arrangement and handling environment.
Custom project supply.
The project configuration connects automated crane movements to scheduling and inventory-management systems. Handling records support material tracking and queries through the utility warehouse workflow.
For a similar project, connect a scanning-equipped crane to WCS dispatch and WMS inventory records. Position feedback, intelligent lifting gear, obstacle detection and anti-sway allow each pickup and release to be logged and supervised from the control room.
Continue from the project to the right crane family.
Use the project as a reference and specify the crane against your own yard layout and cargo.
Prepare a comparable crane quotation.
Share the load schedule and site drawings. Connect a scanning-equipped crane to WCS dispatch and WMS inventory records. Position feedback, intelligent lifting gear, obstacle detection and anti-sway allow each pickup and release to be logged and supervised from the control room.
We can quote a single crane or a coordinated fleet. The offer sets out the destination standards, required certificates and inspection records, manufacturing programme after drawing approval, shipment, installation support and agreed acceptance scope.
- Cable package dimensions and mass
- Storage and vehicle layout
- Inventory and WCS/WMS interfaces
- Obstacle, sway and release rules
- Destination standards, quantity and inspection documentation
- Manufacturing programme, shipment, commissioning, training and spares
