HENAN MINE CRANE / GANTRY CRANES
Double-Trolley Truss Gantry Crane
MEH uses a lattice girder and two trolleys to move long components across an outdoor work area. The lifting plan must address tandem loading, travel path, wind exposure and the transport size of the assembled crane sections.
MEHModel designation5–50 t familyRated load selection
PRODUCT CONFIGURATION / MEHTHE LIFTING TASK
Designed for your handling path.
MEH uses a lattice girder and two trolleys to move long components across an outdoor work area. The lifting plan must address tandem loading, travel path, wind exposure and the transport size of the assembled crane sections.
Crane arrangement
Truss / two trolleys with Two hooks.
MODEL MEH
Technical configuration
Size the crane against the load, installation geometry and work cycle. The final equipment schedule follows the project drawings and operating brief.
Rated capacity5–50 t family
Crane span12–30 m family
Lifting height6–18 m family
Duty classA3–A5
Bridge / structureTruss / two trolleys
Lifting systemTwo hooks
Control arrangementPendant or radio remote to suit operator visibility
Power supplyMatch voltage and frequency to the destination site
Runway and foundationsCheck rail gauge, wheel loads and foundation design
Hook approach and clearanceConfirm required lifting envelope against the site drawings
BUYER'S SELECTION GUIDE
Specify the crane around the job.
Precast and construction yards
Compare the Gantry Cranes range ↗Load and lifting attachment
Share the maximum lifted mass, load dimensions, center of gravity and any grab, magnet, spreader or lifting beam.
Rails and working envelope
Confirm rail gauge, runway length, foundation capacity, cantilever and end approaches.
Duty and controls
State typical load, lifts per hour, travel distance, shifts, control position and site power supply.
Model-specific check
Tandem lift; wind; transport sections
PRODUCT PHOTOS
See the MEH configuration.
Review the equipment arrangement alongside your proposed site layout and lifting route.
TALK TO OUR ENGINEERS
Get a MEH crane proposal.
Send the load schedule and site drawings. We can configure the crane, lifting system and installation interface for your operating conditions.
Request a technical proposal ↗- Maximum lifted load and attachment
- Span, travel length and available clearances
- Daily lifting cycle and control choice
- Power supply, environment and destination
