ME New-Design Double-Trolley Gantry Crane

ME provides two travelling lifting points for independent tasks or permitted joint handling. Its arrangement includes encoder feedback and variable-frequency control. Start with load geometry and lifting sequence; agree useful trolley spacing, individual and shared-load limits and hook coverage for pickup, transfer and placement.

Trolleys
Two travelling lifting trolleys
Modes
Independent or joint operation
Feedback
Encoder-based trolley control
ME double-girder gantry crane with two bridge-mounted trolleys
Twin-trolley layout reference — manufacturer rendering.Product arrangement rendering
01 / APPLICATIONS

Where the ME
fits the work.

01

Long fabricated components

Support a long component at its intended lifting points during transfer. Review the load length, centre of gravity and separation needed between the hook positions.

02

Large assembly handling

Plan a two-point lift for an assembly that needs controlled orientation between stations. Describe the pickup, travel and placement sequence so the proposed joint motions match the task.

03

Independent work positions

Use the two trolleys for separate tasks where the selected arrangement permits. Consider their work zones, operator visibility and how independent operations fit the shared crane route.

02 / TECHNICAL SPECIFICATIONS

ME specifications
and equipment configuration.

Compare the lifting mechanism, control functions and site interfaces for the selected crane.

ME technical specifications and configuration
ModelMETrolley arrangementTwo travelling lifting trolleys
Operating modesTrolleys can operate independently or jointlyWorking-class rangeA3–A8; select the class for the operating cycle
Travel drivesThree-in-one direct-connected crane and trolley travel drivesTrolley feedbackEncoder-based double-trolley control
Drive controlVariable-frequency drive control with CI-card functionalityCantilever arrangementOne side, both sides or no cantilever, according to the selected layout
Working motionsVertical lifting, cross travel and crane long travelRated lifting capacitySpecify the rating of each trolley and the permitted combined lifting load
SpanRail-centre span selected for the working areaLifting heightWorking lifting height selected for the pickup and placement levels
Lifting-point spacingUsable trolley separation selected for the load geometryCoordinated controlLoad sharing, positioning and permitted joint motions defined for the handling sequence
Projection warning lightHoisting-area projection light available by configurationLifting attachmentHook or other specified attachment matched to the handling task
Lifting and travel speedsWorking and positioning speeds specified for each motionOperator controlsOperator position and independent / joint control functions specified
Electrical supplySite voltage, frequency, phases and power-feed route specifiedRunway reactionsWheel-load and horizontal-reaction schedule supplied for the selected arrangement

Capacity, span, lifting height and duty are selected together. The agreed equipment schedule and drawing define your crane configuration.

03 / EQUIPMENT VIEWS

See the ME arrangement.

Review the original equipment views alongside the selected crane drawing.

ME complete gantry arrangement, view 1
ME gantry arrangement — manufacturer rendering, view 1.
ME complete gantry arrangement, view 2
ME gantry arrangement — manufacturer rendering, view 2.
ME complete gantry arrangement, view 3
ME gantry arrangement — manufacturer rendering, view 3.
04 / CONFIGURATION

Choose the ME equipment and site interfaces.

01 / OPTION

Load geometry and trolley ratings

Provide dimensions, centre of gravity, lifting points and required separation. State each trolley’s rating, hook height and lifting speed plus permitted shared-load limits; define which tasks use one trolley and which require both.

02 / OPTION

Coordination and travel equipment

Three-in-one direct-connected crane and trolley drives, encoder feedback and variable-frequency control form the described arrangement. Agree independent/joint commands, permitted motions, feedback and positioning behavior for the handling sequence.

03 / OPTION

Coverage and operator view

Check approaches, leg opening and the complete load route. Select one-sided, two-sided or no cantilever with the relevant load and operating mode. A projection warning light can be specified for the lifting area; agree operator location and visibility of both hooks.

04 / OPTION

Cycle and site interfaces

State load spectrum, lift frequency and shifts. Select duty, mechanism speeds, wheel and horizontal reactions, wind provisions and site power as one crane configuration; coordinate power feed and access to both trolley mechanisms.

05 / PURCHASING & DELIVERY

Confirm the complete ME supply scope.

ORDER

Order quantity

Request one complete ME or a multi-crane project. Give the load geometry, individual trolley needs, shared-lift requirement, span, lifting height and destination.

QUOTATION

Equipment and quotation scope

Compare the two hoisting packages, feedback and coordination functions, operator controls, rails and power feed where included. The written scope should identify optional equipment.

DOCUMENTS

Drawings and equipment documents

Agree the arrangement drawing, trolley spacing, rated-load information, control description, electrical documents and operating instructions for the selected independent and joint modes.

ACCEPTANCE

Standards and acceptance

State destination standards and document requirements. Confirm factory and load-test scope, including the operating modes to be demonstrated and any agreed third-party inspection.

DELIVERY

Delivery and installation

Request manufacturing and delivery timing for the selected control and mechanism package. Coordinate transport sections, assembly access, runway work and commissioning responsibilities.

SUPPORT

Warranty and spare parts

Include operator instruction for mode selection and joint handling in the agreed scope. Record warranty terms, service arrangements and spare parts for the installed system.

CONTINUE YOUR COMPARISON

Compare related
gantry arrangements.

All 16 double-girder gantry models ↗
07 / QUESTIONS BEFORE ORDERING

Choose the ME
with the job in view.

Compare the handling task, selected lifting equipment and supply scope before ordering.

Can the ME trolleys work separately?

The model supports independent and joint operation. The selected equipment and control schedule should identify the rating, motions and operator selection permitted in each mode for your crane.

Can I simply add the trolley ratings?

Use the permitted combined lifting load stated for the selected arrangement. Load geometry and lifting-point distribution must be considered. A pair of individual ratings alone does not define a permitted joint lift.

What dimensions matter for a long load?

Provide load length and width, lifting-point spacing and centre of gravity. Compare them with usable trolley separation, hook approach and leg clearance through pickup, travel and placement.

What does encoder-based control mean for my purchase?

The control arrangement includes encoder feedback. Ask the proposal to name the positioning, indication and coordination functions included for your task, rather than assuming a particular automatic sequence or precision.

Can one operator control both trolleys?

Define the intended operator arrangement and joint-lift sequence in the enquiry. The selected control scope should explain mode selection, operator authority and visibility for both lifting points.

Is every ME a shipbuilding crane?

This ME is the new-design double-trolley gantry arrangement described here. Shipbuilding requirements are a specialised selection and should be stated separately; unrelated shipbuilding ratings are not the general specification of this model.

How do I select the working class?

The A3–A8 family range requires a selected class for your load spectrum, cycle and shifts. State how often the trolleys work individually and jointly so the mechanism selection reflects both uses.

What should my first enquiry include?

Send the load, span, lifting height and destination. Add lifting-point spacing or a load sketch when available. Unknown dimensions can remain open while the initial arrangement and quotation scope are discussed.

08 / YOUR ME GANTRY PROJECT

Get a quotation
for your ME crane.

Tell us what you lift, the approximate span, the required lifting height and your destination. If a dimension is unknown, describe the task and leave that field open.
