MC / Electromagnetic material handling

MC Electromagnetic Gantry Crane

MC handles suitable ferromagnetic material with an electromagnetic lifting system on a double-girder gantry. Variable-frequency motion and the selected magnet serve pickup, transfer and stacking. Define material form and conditions, include magnet weight in the suspended load, and agree the power, holding and release functions.

Attachment
Electromagnetic lifting system
Motion
Variable-frequency crane control
Material focus
Suitable ferromagnetic material
MC complete gantry arrangement, view 1
MC gantry arrangement — manufacturer rendering.Product arrangement rendering
01 / APPLICATIONS

Where the MC
fits the work.

01

Scrap receiving and sorting areas

Transfer suitable ferromagnetic scrap between defined pickup and release positions. Describe how material is presented and the required working area so the attachment selection reflects the load.

02

Billet and steel stockyards

Handle suitable steel material with a magnet arrangement matched to its shape and dimensions. Include stack levels and transfer positions in the layout and lifting-height discussion.

03

Supply to a process area

Serve repeated steel-material transfer between storage and process positions. Define pickup, travel, release and return so the selected duty and electrical functions reflect the whole cycle.

02 / TECHNICAL SPECIFICATIONS

MC specifications
and equipment configuration.

Compare the lifting mechanism, control functions and site interfaces for the selected crane.

MC technical specifications and configuration
ModelMCCrane structureDouble-girder electromagnetic gantry
Lifting attachmentIntegrated electromagnetic lifting systemMaterial focusFerromagnetic material such as suitable scrap and steel billets
Motion controlVariable-frequency control throughout the craneStructural arrangementModular crane design
WheelsForged wheelsTransmission couplingCrowned gear coupling
Rope drumRolled steel-plate drumProtection functionsOverload protection, travel limits, buffers and wind protection
Cantilever arrangementOne side, both sides or no cantilever, according to the selected layoutRated suspended loadMaterial plus magnet, suspension and connecting equipment
SpanRail-centre span selected for the working areaLifting heightWorking lifting height selected for the pickup and placement levels
Magnet selectionMagnet arrangement selected for steel form, load condition and temperatureMagnet electrical packagePower supply, holding / release functions and any backup requirements defined in the offer
Working classSelected for the magnet handling cycle, load spectrum and shiftsMotion speedsLifting, trolley and crane-travel speeds specified for the work route
Operator controlsOperator position, visibility and magnet control functions selected togetherRunway and wind interfaceWheel reactions and specified wind-restraint provisions coordinated with the site

Capacity, span, lifting height and duty are selected together. The agreed equipment schedule and drawing define your crane configuration.

03 / EQUIPMENT VIEWS

See the MC arrangement.

Review the original equipment views alongside the selected crane drawing.

MC complete gantry arrangement, view 1
MC gantry arrangement — manufacturer rendering, view 1.
MC complete gantry arrangement, view 2
MC gantry arrangement — manufacturer rendering, view 2.
MC lifting trolley and hook assembly
MC lifting trolley and hook assembly — manufacturer detail rendering.
04 / CONFIGURATION

Choose the MC equipment and site interfaces.

01 / OPTION

Material and magnet selection

Describe steel form, dimensions or size distribution, condition, temperature and presentation. Select magnet geometry and suspension for pickup and release; include magnet, connecting equipment and material in the complete suspended load.

02 / OPTION

Electrical operating functions

Define magnet supply and control circuits, energising, holding and release behavior and any required backup functions. The offer should identify material assumptions, selected electrical equipment and operator visibility of pickup, travel and release.

03 / OPTION

Motion and working coverage

Variable-frequency control applies throughout the model arrangement. Match lifting and travel speeds to load spectrum, shifts and placement. Choose one-sided, two-sided or no cantilever; check lifting levels, transfer distance and final supporting reactions.

04 / OPTION

Protection and maintenance

The model description includes overload protection, travel limits, buffers and wind protection. Coordinate power feed, restraints and corrosion exposure. Review access to modular mechanisms, forged wheels, crowned gear couplings and rolled steel-plate drums with the selected crane and magnet package.

05 / PURCHASING & DELIVERY

Confirm the complete MC supply scope.

ORDER

Order quantity

Request one complete MC or a larger project. Provide the material description, required load, span, lifting height and destination, marking any dimensions still unknown.

QUOTATION

Equipment and quotation scope

Compare the magnet and suspension, electrical package, crane mechanisms, controls and included site interfaces. Confirm whether rails, power feed, freight and installation services form part of the price.

DOCUMENTS

Drawings and equipment documents

Agree the crane arrangement, magnet data, load assumptions, electrical drawings, control description and operating instructions for the selected material and handling modes.

ACCEPTANCE

Standards and acceptance

State applicable destination standards and document requirements. Define factory checks, load testing and the magnet functional demonstrations included in acceptance, with any third-party inspection agreed in advance.

DELIVERY

Delivery and installation

Confirm manufacture and shipping timing for the selected crane and magnet equipment. Allocate installation, electrical connections, commissioning and operator instruction responsibilities.

SUPPORT

Warranty and spare parts

Record the warranty period, starting point, service arrangements and spare-parts scope for the complete supplied system. Discuss support at the destination and access to the electrical and mechanical equipment.

CONTINUE YOUR COMPARISON

Compare related
gantry arrangements.

All 16 double-girder gantry models ↗
07 / QUESTIONS BEFORE ORDERING

Choose the MC
with the job in view.

Compare the handling task, selected lifting equipment and supply scope before ordering.

Can MC lift every type of metal?

MC is selected for suitable ferromagnetic material. Provide the actual material composition or designation, form, dimensions and condition so the magnet package can be assessed for the intended pickup and release task.

Does the crane rating include the magnet?

Use the complete suspended load: material, magnet, suspension and connecting equipment. Ask the offer to distinguish the crane capacity from the intended material load under the selected magnet arrangement.

What happens if electrical power is interrupted?

Specify the holding and backup functions required by the application. The proposal should identify the included equipment, operating behaviour and limitations. Do not assume a backup package from the model name alone.

Are lifting and travel variable-frequency controlled?

The MC model description includes variable-frequency control throughout the crane. Confirm the selected drive equipment, motion speeds and operator functions in the technical schedule for your configuration.

Can MC load material outside the rail span?

Cantilever arrangements can be selected on one side, both sides or neither. Define the outside-span pickup or discharge position and load so the required coverage and reactions can be confirmed.

Which material information changes magnet selection?

The material form, dimensions, presentation, condition and relevant temperature all belong in the enquiry. Include the intended weight per pickup and where the material must be released or stacked.

How should I compare magnetic-handling quotations?

Compare the same material assumptions, suspended load, working route, magnet and electrical functions. Include crane duty, speeds, site interfaces, inspection scope and delivery services alongside the price.

Can I start with an estimated working area?

Yes. Send estimated span and lifting height, load, destination and a short material description. Unknown dimensions can be confirmed as the layout develops. A photo of the pickup and release areas can help.

08 / YOUR MC GANTRY PROJECT

Get a quotation
for your MC crane.

Tell us what you lift, the approximate span, the required lifting height and your destination. If a dimension is unknown, describe the task and leave that field open.
