HENAN MINE CRANE / ELECTRIC HOIST GANTRY CRANES
Grab and Hook Electric Hoist Gantry Crane
One runway for bulk and general loads.
The grab-and-hook arrangement serves loose material and conventional suspended cargo. Size both operating modes, including the grab self-weight and the maximum hook load.
MHZEModel designation1–20 tRated load selection
PRODUCT CONFIGURATION / MHZETHE LIFTING TASK
Designed for your handling path.
The grab-and-hook arrangement serves loose material and conventional suspended cargo. Size both operating modes, including the grab self-weight and the maximum hook load.
Crane arrangement
Full gantry with Grab and hook.
MODEL MHZE
Technical configuration
Size the crane against the load, installation geometry and work cycle. The final equipment schedule follows the project drawings and operating brief.
Rated capacity1–20 t
Crane span6–30 m
Lifting height4–18 m
Duty classA5
Bridge / structureFull gantry
Lifting systemGrab and hook
Control arrangementPendant or radio remote to suit operator visibility
Power supplyMatch voltage and frequency to the destination site
Runway and foundationsCheck rail gauge, wheel loads and foundation design
Hook approach and clearanceConfirm required lifting envelope against the site drawings
BUYER'S SELECTION GUIDE
Specify the crane around the job.
Mixed bulk-material and general-cargo yards
Compare the Electric Hoist Gantry Cranes range ↗Load and lifting attachment
Share the maximum lifted mass, load dimensions, center of gravity and any grab, magnet, spreader or lifting beam.
Rails and working envelope
Confirm rail gauge, runway length, foundation capacity, cantilever and end approaches.
Duty and controls
State typical load, lifts per hour, travel distance, shifts, control position and site power supply.
Model-specific check
Material density; grab volume; hook load; changeover frequency
PRODUCT PHOTOS
See the MHZE configuration.
Review the equipment arrangement alongside your proposed site layout and lifting route.
TALK TO OUR ENGINEERS
Get a MHZE crane proposal.
Send the load schedule and site drawings. We can configure the crane, lifting system and installation interface for your operating conditions.
Request a technical proposal ↗- Maximum lifted load and attachment
- Span, travel length and available clearances
- Daily lifting cycle and control choice
- Power supply, environment and destination
