Where it fits
Cross-bay maintenance and transfer
HENAN MINE CRANE / ELECTRIC HOIST OVERHEAD CRANES
KSX Track-Switching Overhead Crane
Transfer the crane between connected tracks.
KSX is described for power-station coal-mill maintenance and cross-area handling. The track interface, switch sequence and interlocks must be designed around the site.
KSXModel designation1–32 tRated load selection
PRODUCT CONFIGURATION / KSXTHE LIFTING TASK
Designed for your handling path.
KSX is described for power-station coal-mill maintenance and cross-area handling. The track interface, switch sequence and interlocks must be designed around the site.
Crane arrangement
Electric Hoist Overhead Cranes with Track-switching bridge.
MODEL KSX
Technical configuration
Size the crane against the load, installation geometry and work cycle. The final equipment schedule follows the project drawings and operating brief.
Rated capacity1–32 t
Crane span3–30 m
Lifting height4–20 m
Duty classA5–A6
Lifting systemTrack-switching bridge
Trolley / attachmentTrack-switching system
ControlTransfer interlock to confirm
Power supplyMatch voltage and frequency to the destination site
Runway and building interfaceCheck runway geometry, wheel loads and building reactions
Hook approach and clearanceConfirm required lifting envelope against the site drawings
BUYER'S SELECTION GUIDE
Specify the crane around the job.
Cross-bay maintenance and transfer
Compare the Electric Hoist Overhead Cranes range ↗Load and lifting attachment
Share the maximum lifted mass, load dimensions, center of gravity and any grab, magnet, spreader or lifting beam.
Runway and building interface
Confirm runway centers, wheel loads, building clearances and hook approaches.
Duty and controls
State typical load, lifts per hour, travel distance, shifts, control position and site power supply.
Model-specific check
Track geometry, transfer interlocks and approach clearances
PRODUCT PHOTOS
See the KSX configuration.
Review the equipment arrangement alongside your proposed site layout and lifting route.
TALK TO OUR ENGINEERS
Get a KSX crane proposal.
Send the load schedule and site drawings. We can configure the crane, lifting system and installation interface for your operating conditions.
Request a technical proposal ↗- Maximum lifted load and attachment
- Span, travel length and available clearances
- Daily lifting cycle and control choice
- Power supply, environment and destination
