Transfer filled ladles between foundry stations with a double-girder bridge and dedicated metallurgical electric hoist.

Start with the information you already have. A load drawing and workshop sketch help us recommend a configuration.
Include metal, vessel, carrier and lifting equipment in one complete load. The double-girder bridge and metallurgical hoist are selected together for the required hook coverage and handling frequency.
Double brakes, dual hoisting limits and overload protection form the dedicated hoist package. The offer describes their functions and the tests required for the supplied crane.
Select lift and travel speeds around the route and placement task. Thermal protection, operator position and maintenance access are developed alongside the production cycle.

Carry a ladle between defined pickup and casting positions. Match the hook interface, hoist rating and travel path to ladle geometry, complete suspended weight and the peak operating cycle.
Bring the ladle to the specified station with suitable hook height and approach control. Where the process requires tilting, include the device, connection and control sequence in the crane proposal.
Suitable hot billets or other metallurgical loads can form part of the ordered duty. Identify their weights, lifting attachments, temperatures and handling frequency so the crane is selected for the intended load mix.
The order identifies permitted molten-metal and hot-load duties. Adding a second brake alone does not convert a general-purpose hoist crane into an LHY metallurgical crane.
Compare the available options for your lifting task. Capacity, span, lift height and speed are matched in the selected configuration.
| Model | LHY |
|---|---|
| Bridge arrangement | Double girder electric-hoist overhead crane |
| Lifting mechanism | Dedicated metallurgical electric hoist |
| Load-handling device | Hook; ladle/attachment interface matched to the application |
| Rated capacity | Selected from metal, ladle, fixture and other suspended loads |
| Span | Matched to production-bay rail-centre distance |
| Lifting height | Matched to ladle pickup, transfer and placement levels |
| Working duty | Selected from load spectrum, lifts per hour and shifts |
| Hoisting speed | Selected for metallurgical lifting and controlled placement |
| Trolley and bridge travel | Selected for route length, cycle and positioning |
| Braking | Double-brake hoist arrangement |
| Overload protection | Metallurgical hoist protection package |
| Hoisting limits | Dual limit protection |
| Wheels | Forged wheels |
| Drive motors | Special-purpose motors matched to the metallurgical configuration |
| Heat and dust protection | Matched to ambient temperature, radiant heat and dust |
| Power supply | Three-phase voltage and frequency matched to destination supply |
| Ladle tilting | Separate handling device/control scope where required |
| Handling duty | Load information | Lifting/control requirement | Protection to specify |
|---|---|---|---|
| Loaded-ladle transfer | Metal + ladle + lifting equipment | Controlled pickup, transfer and placement speeds | Double brakes, overload protection and dual limits |
| Pouring-station supply | Ladle geometry and operating positions | Approach speed and any separate tilting device | Heat exposure and operator visibility |
| Hot billet or metallurgical load | Load temperature, attachment and maximum weight | Lifts/hour, travel distance and placement cycle | Thermal/dust protection and selected duty |
Capacity, span, lifting height and speeds are specified for the selected metallurgical duty. The crane package and permitted loads are stated together in the technical offer.
Compare the hook and hoist-trolley arrangement with the ladle task. The offer identifies the metallurgical hoist, braking and limit functions supplied for your application.


Start with the filled ladle and its lifting interface. Select the bridge, hoist, double-brake and limit package, motion speeds and thermal protection against that load and its operating route.

Provide empty and maximum filled weights, lifting points, carrier dimensions and centre of gravity. Identify any fixture carried by the hook and the clearance needed at pickup and placement.
Set span and hook travel from the runway and station heights. Check trolley approaches, roof clearance, maximum wheel loads and access to the metallurgical hoist.
Describe each brake and hoisting-limit function in the equipment schedule. Agree settings, test methods and acceptance records with the overload protection supplied for the selected hoist.
State loaded travel distance, lifts per hour, shifts and time spent near the hot zone. Select lift, trolley and bridge speeds for transfer and controlled placement with the corresponding mechanism duty.
Give ambient temperature, radiant exposure and dust conditions separately from metal temperature. Match shielding, special-purpose motors, cables and control equipment to the installation.
Agree controls around operator visibility and the ladle route. Specify any separately required tilting device and permitted coordinated movement, together with power-feed and plant-supply requirements.
Ask for one itemised LHY scope covering the bridge, metallurgical hoist, hook interface, double brakes, limits, overload protection, thermal package, controls and power feed. List any tilting device and site services separately, with agreed protection tests, commissioning, training and hoist spares.
Identify the bridge, lifting mechanisms, lifting attachment, heat protection, controls and power feed. State the selected operating modes and equipment boundaries in the offer.
Request the arrangement, lifting-interface drawing, load-and-motion schedule, electrical information, safety-function description and agreed factory/site checks for the ordered crane.
List rails, runway steelwork, attachments, automation, weighing, spares, packing, freight, erection and commissioning as included, optional or excluded.
Agree drawing approval, manufacturing, testing and dispatch milestones for the selected configuration. Include access, shutdown windows and the destination in the delivery plan.
Define erection supervision, power and runway preparation, protection checks, attachment fit, trial operation and operator training, with responsibilities agreed before site work.
Record the warranty terms and commencement, service arrangements and recommended brake, rope, drive, control and attachment spares for the equipment supplied.
Agree load, lifting device, route, duty, thermal conditions and operating modes.
Coordinate hook coverage, attachment fit, runway reactions and site responsibilities.
Complete the agreed checks and records, then coordinate packing and shipment.
Confirm erection, commissioning, operator training and service arrangements.
Technical schedule · General arrangement · Attachment interface · Runway loads · Electrical information · Safety-function description · Agreed inspection records · Operation and maintenance manuals
Review the lifting task, configuration and quotation scope. We can help develop a crane proposal from the project information available.
LHY combines a double-girder bridge with a dedicated metallurgical electric hoist for the specified molten-metal duty. The complete ladle load, required coverage, heat exposure and production cycle determine the final configuration.
LDY uses a top-running single-girder bridge with a dedicated metallurgical hoist. LHY uses a double-girder bridge and its accepted hoist package identifies double brakes, overload protection and dual limits. Compare the complete layout, protection functions, load and process duty for your installation.
The metallurgical hoist incorporates two brakes. The technical offer describes the function of each brake and the inspection and acceptance tests for the selected lifting system. Include the required operating and interrupted-cycle conditions in that review.
The supplied hoist has dual limit protection. The equipment schedule should identify the functions, sequence and settings, with the corresponding checks recorded during commissioning. Hook positions and clearances are established from the ladle and station geometry.
Crane selection uses the complete suspended load, including the metal, empty ladle, carrier, fixture and any other lifting equipment. Send the empty and maximum loaded weights so the bridge and hoist can be selected for the actual duty.
Specify the ladle and pouring method in the enquiry. LHY provides hook lifting and travel; any required tilting device, connection and control function is included as an identified equipment item with a defined permitted sequence.
Provide the full ladle load, span, hook travel, travel distance, lifts per hour and operating shifts. The proposal gives definite ratings and motion speeds for the selected metallurgical duty, including the approach needed at pickup and placement.
Suitable hot billets or metallurgical materials can be reviewed as part of the intended duty. Include their weights, attachments, temperatures and cycles so the permitted load mix is stated in the order and operating instructions.
State material temperature, workshop ambient temperature, radiant exposure, distance from the heat source and dust conditions. The quoted package identifies the thermal conditions and protection applied to the hoist, bridge, drives, cables and controls.
Confirm the ladle interface, crane arrangement, load and motion schedule, hoist protection functions and thermal conditions. Agree drawings, electrical information, test records, manuals and destination documents, plus delivery milestones, warranty terms, installation and commissioning support, training and recommended brake, rope, limit and drive spares.
Send the empty and filled ladle weights, approximate rail-centre span, lifting height and transfer route. Describe the pouring method and operating cycle so we can select the LHY hoist, protection functions and crane arrangement together.
