HENAN MINE CRANE / SINGLE-GIRDER OVERHEAD CRANES
Side-Mounted Single-Girder Crane
A fixed electric hoist mounted to the side of the girder to increase usable vertical working space.
LDPModel designation1–10 tRated load selection
PRODUCT CONFIGURATION / LDPTHE LIFTING TASK
Designed for your handling path.
A fixed electric hoist mounted to the side of the girder to increase usable vertical working space.
Crane arrangement
Offset hoist arrangement with Side-mounted fixed hoist.
MODEL LDP
Technical configuration
Size the crane against the load, installation geometry and work cycle. The final equipment schedule follows the project drawings and operating brief.
Rated capacity1–10 t
Crane span7.5–28.5 m
Lifting height6–30 m
Duty classA3–A5
Hoisting speed3.2–16 m/min
Hoist layoutSide-mounted fixed electric hoist
Lifting mechanismSide-mounted fixed hoist
Bridge structureOffset hoist arrangement
Control arrangementPendant or radio remote to suit operator visibility
Power supplyMatch voltage and frequency to the destination site
Runway and building interfaceCheck runway geometry, wheel loads and building reactions
Hook approach and clearanceConfirm required lifting envelope against the site drawings
BUYER'S SELECTION GUIDE
Specify the crane around the job.
Low clearance work areas
Compare the Single-Girder Overhead Cranes range ↗Load and lifting attachment
Share the maximum lifted mass, load dimensions, center of gravity and any grab, magnet, spreader or lifting beam.
Runway and building interface
Confirm runway centers, wheel loads, building clearances and hook approaches.
Duty and controls
State typical load, lifts per hour, travel distance, shifts, control position and site power supply.
Model-specific check
Hook approach and building section
PRODUCT PHOTOS
See the LDP configuration.
Review the equipment arrangement alongside your proposed site layout and lifting route.
TALK TO OUR ENGINEERS
Get a LDP crane proposal.
Send the load schedule and site drawings. We can configure the crane, lifting system and installation interface for your operating conditions.
Request a technical proposal ↗- Maximum lifted load and attachment
- Span, travel length and available clearances
- Daily lifting cycle and control choice
- Power supply, environment and destination
