MGY Metallurgical Gantry Crane

MGY serves steel-ladle handling or slag-pot maintenance with a double-girder gantry and selected gantry-hook attachment. Key structures receive heat protection. The described system uses stator-voltage lifting control and variable-frequency travel; select the equipment around complete vessel load, thermal exposure and the actual handling sequence.

Application
Steel-ladle handling / slag-pot maintenance
Attachment
Matched gantry-hook arrangement
Thermal provisions
Heat protection for key structures
MGY complete gantry arrangement, view 1
MGY gantry arrangement — manufacturer rendering.Product arrangement rendering
01 / APPLICATIONS

Where the MGY
fits the work.

01

Steel-ladle handling

Describe the ladle, its lifting points, full handling load and the route between process positions. Include the relevant heat exposure and the working levels needed for pickup and placement.

02

Slag-pot maintenance

Plan lifting around the pot condition and the maintenance activity. Confirm the attachment interface, required access and handling sequence rather than treating it as a generic cargo lift.

03

Process-area transfer

Coordinate the crane route with surrounding equipment and the vessel envelope. Review the hook levels, clear passage and transfer positions that belong to the specified metallurgical duty.

02 / TECHNICAL SPECIFICATIONS

MGY specifications
and equipment configuration.

Compare the lifting mechanism, control functions and site interfaces for the selected crane.

MGY technical specifications and configuration
ModelMGYCrane structureMetallurgical double-girder gantry
Lifting attachmentGantry-hook attachment for the selected vesselApplication focusSteel-ladle lifting or slag-pot maintenance
Thermal protectionHeat protection for key main-girder and leg structuresThermal exposureArrangement intended for radiant-heat exposure in metallurgical work
Control platformPLC module with HMI touch screenMaster controllerWLK controller with defined steps, zero-return and locking functions
Lifting controlStator-voltage regulation for lifting speed controlTravel controlVariable-frequency travel-speed control
Structural designKey load-bearing members optimised by finite-element analysisRated lifting capacityVessel, contents, lifting attachment and connecting equipment assessed together
SpanRail-centre span selected for the working areaLifting heightWorking hook levels selected for vessel pickup, transfer and maintenance
Vessel interfaceGantry-hook geometry and engagement matched to the vessel lifting pointsProcess and dutyLoad spectrum, handling sequence, shifts and required operating modes specified
Heat conditionsVessel temperatures and radiant-heat exposure stated for the selected equipmentLifting and travel speedsLoaded, positioning and travel speeds specified for the process
Electrical packageSite supply, protection and cable routing selected for the environmentRunway reactionsRail interface, wheel loads and relevant horizontal reactions provided for the selected crane

Capacity, span, lifting height and duty are selected together. The agreed equipment schedule and drawing define your crane configuration.

03 / EQUIPMENT VIEWS

See the MGY arrangement.

Review the original equipment views alongside the selected crane drawing.

MGY complete gantry arrangement, view 1
MGY gantry arrangement — manufacturer rendering, view 1.
MGY complete gantry arrangement, view 2
MGY gantry arrangement — manufacturer rendering, view 2.
MGY complete gantry arrangement, view 3
